LEA Connect 704 IoT-Enabled Professional Amplifier
Customer Care -

LEA Connect 704 IoT-Enabled Professional Amplifier

LEA Connect 704 IoT-Enabled Professional Amplifier

LEA Connect 704 IoT-Enabled Professional Amplifier

  • Vendor: Bliaudio-sgh
  • Shipping Origins: Jakarta Pusat, DKI Jakarta
  • Product Code: LEA Connect 704 IoT-Enabled Professional Amplifier
  • Availability: In Stock
  • Rp 44,900,000

Memperkenalkan amplifier profesional yang memiliki fitur Internet of Things- (IoT) pertama di dunia - NETWORK CONNECTSERIES. Sangat cocok untuk instalasi skala kecil hingga menengah, dua, empat, dan delapan channel amp ini memiliki fitur HiZ (70V atau 100V) atau LoZ yang dapat dipilih berdasarkan channel. Dengan tiga cara untuk terhubung, Anda dapat menggunakan titik akses Wi-Fi built in dari amplifier, menghubungkan ke Wi-Fi yang ada di dalam venue, atau menggunakan Ethernet untuk menghubungkan ke local area network melalui kabel Cat5 atau Cat6.

NETWORK CONNECTSERIES adalah amplifier profesional pertama yang menampilkan konektivitas Cloud. Manfaatkan kekuatan Cloud untuk kendali jarak jauh, pemantauan, pemberitahuan, dan lainnya dari perangkat pribadi anda di manapun dan kapanpun. Cukup hubungkan amplifier anda ke jaringan anda. Daftarkan akun LEA Cloud gratis Anda di leaprofessional.cloud


  • Output : 4 x 700 WRMS @ 4Ω, 8Ω, 70V, 100V (350W at 2Ω)
  • Inputs : Balanced analog Inputs with user selectable 26 dB and 34 dB input sensitivity
  • THD+N : 0.1% (20Hz to 20kHz)
  • Frequency Response : +/- 0.5 dB @ 4Ω, 8Ω, 70V, 100V, -2.5dB @ 20kHz at 2Ω
  • Signal to Noise Level : 105dB (20Hz to 20kHz referenced to 8Ω)
  • Crosstalk : 70dB (20Hz to 20kHz)
  • I/O Latency : 1 ms DSP latency under any condition
  • Load Impedance : LowZ down to 2 ohms, 70V direct, and 100V Direct per channel
  • Amplifier Output Classification : Class D with Proprietary Smart Power Bridge Technology allowing bridged output functionality without sacrificing an amplifier channel
  • DC : Offset +/- 3mV
  • DSP : Architecture Analog Devices Sigma 96kHz DSP Processor with 32-bit Core with Sample Rate Converters
  • Input Matrix : Routable matrix; any input to any output with primary and secondary input priority
  • Crossovers : Up to 48 dB/Octave IIR Filters (Linkwitz Riley and Butterworth)
  • Parametric EQ : 8 Band Parametric EQ per channel
  • Output Delay : 100ms per channel
  • Output Protection : DC, VHF, and AC Mains Protection, Overtemp and Current Limiter, fan fault detection
  • User Adjustable : Limiting Peak Voltage and RMS Voltage
  • Load Monitoring : Realtime Load Monitoring and Pilot Tone Detection from Internal or External Sources
  • Network Connectivity : WiFi or 100MB Ethernet with PoE or Built in WiFi Access Point (IEEE 802.11 b/g/n WPA, WAP2, WEP) Operating Frequency: 2412 – 2472MHz ; Channel Spacing:5Mhz ; Modulation: DSSS, OFDM
  • User Interface Web Browser : User Interface or 3rd Party API control (Q-Sys coming soon)
  • Supported Operating Systems : MAC, iOS, PC, Android
  • External I/O : External I/O In: Toggles Remote On/Off | External I/O Out: Indicates Amplifier Health | Cloud IoT Cloud-based IoT functionality
  • AC Mains : 100VAC - 240VAC +/- 15% 50Hz or 60Hz
  • Temperature : Storage: -20°C to 90° C - Operating: 0°C to 60° C
  • Power Supply : Universal Switch Mode Power Supply with Power Factor Correction (No PFC in 84, 164, 88, & 168)
